Fast Delivery Manufacturer Single Phase 50VA 10kV Input Voltage Control Power Transformer Isolation Electric Transformer

Manufacturer 50VA Control Transformer Model: RBK-50 Product Overview Selection of Toroidal Transformer Toroidal Transformers offer many advantages over standard laminated power transformers. Toroidals provide quiet, efficient operation with very low stray magnetic fields. Their small size and weight support a package that is easy to design into any application. Advantages of Toroidal Transformer: 1. A toroidal transformer weighs about half as much as conventional transformer with the same capacity and heat rise. The main materials used in transformer are copper and steel, both of which are getting scarcer with cost increases as a consequence. 2. No impregnation is needed to keep the laminates quiet so this potential environmental hazard is avoided. 3. The toroidal transformer fits into a smaller space, which allows chassis plates and enclosures to be smaller with less material used. How to find VA for Transformers Volt amps (VA) is the effective power rating for a transformer. In the perfect transformer, the voltage and current (combined) applied at the primary will exactly equal the voltage and current (combined) on the secondary(s). Efficiency is measure of a transformer’s ability to delivery the input power to the load. Efficiency is expressed as a percent by: % = ( PO / PI ) X 100 (Where: PO = Output power, PI = Input power, % = Efficiency) VA Calculation 1. Read the transformer’s secondary winding rating (printed or tagged on the transformer case). This should give a rating such as 5V, 500mA. Multiply the voltage times the current to receive the VA. Example: 5V times 500mA (or 0.5A) equals 2.5VA 2. Convert the secondary winding VA value to the primary winding VA rating as the equation VA (Primary) equals VA (Secondary) or VA (p) = VA(s) For example of a 2.5VA secondary, if the primary voltage is 120V the current will be A (p) = VA(s) / V(p). Giving A(p) = 2.5 / 120 = 0.020833 (roughly 21mA). This is the calculation for a single input winding/single output winding transformer. 3. Add the separate VA ratings for a transformer with multiple secondary windings. For secondary winding 1 = 5VA at 500mA Secondary winding 2 = 24V at 100mA Total Secondary VA = ( 5 X 0.5 ) + ( 24 X 0.1 ) = 4.9VA Primary VA will still equal the total secondary VA. Specifications Capacity..............................................................................50VA Frequency..........................................................................50/60Hz Voltage Combination.......................................................Pls. see selection form. Winding Material...............................................................100% Copper Terminal Block Connection............................................Provided Metallic Bracket Mounting...............................................Provided Standards...............................................VDE0550, IEC204-1, IEC61588,EC439 Sample Service..................................................................Pay to Provide Quality Assurance.............................................................24 months Item Condition....................................................................Brand-New Selection Form Item Capacity Voltage Combination Case Qty. Model (VA) Primary (V)/Secondary (V) (Pcs) RBK-50 440/220;240/24;220/24; 220-380/110-60-48-24, 380/220-110 RBK-100 100 RBK-150 150 RBK-200 200 RBK-250 250 RBK-300 300 RBK-400 400 RBK-500 500 RBK-700 700 RBK-1000 1000 RBK-1500 1500 RBK-2000 2500 Note: Please mention the voltage combination when ordering. Other else multiple voltage combination upon request. Dimension Company Information Packaging & Shipping Why choose us 1. Experienced manufacturer more than 10 years. 2. Highly experienced production team in YOMIN factory work-shop. 3. QC Systerm: Quality controlled on all production lines, and QC inspectors work independently from the production line. 4. Good quality production with quick delivery. 5. Accepted OEM/ODM. 6. Accepted small MOQ. 7. Trade Assurance on Alibaba. 8. Factory certification: CE, RoHS and ISO9001 . Contatc us
